Medium 2.5-inch C17 series
C17 Series
2.5"SUS304 Medium-duty caster,Capacity 40-90Kg
Housing:SUS304,3.0mm
Housing Thickness:SUS304,2.5mm
Wheel Type:PU,90±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreA -20℃-60℃
Wheel bearings:Derlin Bush,Stainless steel bearing on request.
Housing:SUS304,3.0mm
Housing Thickness:SUS304,2.5mm
Wheel Type:PU,90±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreA -20℃-60℃
Wheel bearings:Derlin Bush,Stainless steel bearing on request.
|
Rotating
|
ART.NO..
|
|
|
|
|
|
TreadTread |
Frame |
STD Bearing | Option Bearing |
|
Wheel Dia.(mm)
|
Tread Width（mm） | Mounting Height （mm） | Housing Thickness/Load（mm） | Caster Capacity（kg） | ||||||
| plate Rigid | M-DP58-6331WSUS304 | 2.5”/63 | 93.5 | 75.5 | 2.5mm/120kg | 90 | PP | PP | Steel Double bail Double shaft 6001 | 1.Derlin+304 Tube/Teling's 4th digit changed to 6 2.440C Double bail Change the 4th digit of double shaft 440c-6001 to B 3.SUS304 Double bail Double axis 304-6001 4th digit changed to s |
| M-DP08-6331WSUS304 | 2.5”/63 | 31 | 93.5 | 2.5mm/120kg | 90 | PU | PP | Steel Double bail Double shaft 6001 | ||
| M-DP38-6331WSUS304 | 2.5”/63 | 31 | 93.5 | 2.5mm/120kg | 70 | TPR | PP | Steel Double bail Double shaft 6001 |
