Medium 3-inch C18 series
C18 Series
3"SUS304 Medium-duty caster,Capacity 50-100Kg
Housing:SUS304,3.0mm/2.5mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreA -20℃-60℃
Fiberglass+PA，-35℃-200℃
Wheel bearings:Single bearing6002，Double bearings 6001
Bearing material：Stainless steel 440C/SUS304/Derlin on option
Housing:SUS304,3.0mm/2.5mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreA -20℃-60℃
Fiberglass+PA，-35℃-200℃
Wheel bearings:Single bearing6002，Double bearings 6001
Bearing material：Stainless steel 440C/SUS304/Derlin on option
|
Rotating
|
ART.NO..
|
|
|
|
|
|
Tread |
Frame |
STD Bearing | Option Bearing |
|
Wheel Dia.(mm)
|
Tread Width（mm） | Mounting Height （mm） | Housing Thickness/Load（mm） | Caster Capacity（kg） | ||||||
| Plate Rigid | M-DP02-7531GSUS304 | 3”/7.5 | 31 | 108.5 | 2.5mm/170kg | 100 | PU | PP | Steel Double bail Single shaft 6002 | 1.Derlin+304 Tube/Teling's 4th digit changed to 6 2.440C Double bail Change the 4th digit of double shaft 440c-6001 to B 3.SUS304 Double bail Double axis 304-6001 4th digit changed to s 3.SUS304 Double bail Single axis 304-6002 4th digit changed to C |
| M-DP32-7531GSUS304 | 80 | TPR | PP | |||||||
| M-DP08-7531GSUS304 | 100 | PU | PP | Steel Double bail 双轴6001 | ||||||
| M-DP58-7531GSUS304 | 33 | 100 | PP | PP | ||||||
| M-DP38-7531GSUS304 | 80 | TPR | PP | |||||||
| M-DPFH-7533GSUS304 | 100 | Fiberglass+PA | Fiberglass+PA | Hi-temp steel double | / |
