Medium 4-inch C19 Series
C19 Series
4" SUS304 Medium-duty caster,Capacity60-110Kg
Housing:SUS304,3.0mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6001, Double bearings6001
Bearing material:Stainless steel 440C440C/SUS304/Derlin on option
Housing:SUS304,3.0mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6001, Double bearings6001
Bearing material:Stainless steel 440C440C/SUS304/Derlin on option
|
Rotating
|
ART.NO..
|
|
|
|
|
|
Tread |
Frame |
STD Bearing | Option Bearing |
|
WPeel Dim.(mm)
|
Offset(mm) | Mounting Height(mm) | Housing Thickness/Load(mm) | Caster Capacity(kg) | ||||||
| plate Swivel | M-WP02-10031GSUS304 | 4”/100*31 | 32 | 132 | 2.5mm/170kg | 110 | PP | PP | Steel Double bail 单轴6002 | 1.Derlin+304 Tube/特尔灵 第4位数字改成6 2.440C Double bail 双轴 440C-6001 第4位数字改成B 3.SUS304 Double bail 双轴 304-6001 第4位数字改成S 4.SUS304 Double bail 单轴 304-6002 第4位数字改成C |
| M-WP32-10031GSUS304 | 90 | TPR | PP | |||||||
| M-WP08-10031GSUS304 | 110 | PU | PP | Steel Double bail 双轴6001 | ||||||
| M-WP58-10031GSUS304 | 110 | PP | PP | |||||||
| M-WP38-10031GSUS304 | 90 | TPR | PP | |||||||
| M-WPFH-10033GSUS304 | 4”/100*33 | 110 | Fiberglass+PA | Fiberglass+PA | Hi-temp steel double ball 高温双轴6001 | / | ||||
| plate TT brake | M-ZP02-10031GSUS304 | 4”/100*31 | 30 | 132 | 2.5mm/170kg | 110 | PU | PP | Steel Double bail 单轴6002 | 1.Derlin+304 Tube/特尔灵 第4位数字改成6 2.440C Double bail 双轴 440C-6001 第4位数字改成B 3.SUS304 Double bail 双轴 304-6001 第4位数字改成S 4.SUS304 Double bail 单轴 304-6002 第4位数字改成C |
| M-ZP32-10031GSUS304 | 90 | TPR | PP | |||||||
| M-ZP08-10031GSUS304 | 110 | PU | PP | Steel Double bail 双轴6001 | ||||||
| M-ZP58-10031GSUS304 | 110 | PP | PP | |||||||
| M-Z38-10031GSUS304 | 90 | TPR | PP | |||||||
| M-ZPFH--10033GSUS304 | 4”/100*33 | 110 | Fiberglass+PA | Fiberglass+PA | Hi-temp steel double ball 高温双轴6001 | / |
