Medium 5-inch C20 Series
C20 Series
5" SUS304 Medium-duty caster,Capacity70-120Kg
Housing:SUS304,3.0mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6001, Double bearings6001
Bearing material:Stainless steel 440C440C/SUS304/Derlin on option
Housing:SUS304,3.0mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6001, Double bearings6001
Bearing material:Stainless steel 440C440C/SUS304/Derlin on option
|
Potating
|
ART.NO..
|
|
|
|
|
|
Tread |
Frame |
STD Bearing | Option Bearing |
|
Wheel Dia(mm)(mm)
|
Tread Width(mm) | Mounting Height(mm) | Housing Thickness/Load(mm) | Caster Capacity(kg) | ||||||
| plate Rigid | M-DP02-12531GSUS304 | 5”/125 | 31 | 161 | 2.5mm/170kg | 120 | PU | PP | Steel Double bail 单轴6002 | 1.Derlin+304 Tube/特尔灵 第4位数字改成6 2.440C Double bail 双轴 440C-6001 第4位数字改成B 3.SUS304 Double bail 双轴 304-6001 第4位数字改成S 3.SUS304 Double bail 单轴 304-6002 第4位数字改成C |
| M-DP32-12531GSUS304 | 100 | TPR | PP | |||||||
| M-DP08-12531GSUS304 | 120 | PU | PP | Steel Double bail 双轴6001 | ||||||
| M-DP58-12531GSUS304 | 33 | 120 | PP | PP | ||||||
| M-DP38-12531GSUS304 | 100 | TPR | PP | |||||||
| M-DPFH-12533GSUS304 | 120 | Fiberglass+PA | Fiberglass+PA | Hi-temp steel double | / |
