EURO Medium 3-5-inch E19 Series
E19 Series
3" - 5” SUS304 Medium-duty caster,Capacity50-120Kg
Housing:SUS304,3.0/2.5mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6002, Double bearings6001
Bearing material:Stainless steel 440C/SUS304/Derlin on option
Housing:SUS304,3.0/2.5mm
Wheel Type:PU,92±3 ShoreA -30℃-70℃
TPR,80±3 ShoreA -20℃-50℃
PP,85±3 ShoreD -20℃-60℃
Fiberglass+PA,-35℃-200℃
Wheel bearings:Single bearing6002, Double bearings6001
Bearing material:Stainless steel 440C/SUS304/Derlin on option
|
Potating
|
ART.NO..
|
|
|
|
|
|
Tread |
Frame |
STD Bearing | Option Bearing |
|
Wheel Dia(mm)
|
Tread Width(mm) | Mounting Height(mm) | Housing Thickness/Load(mm) | Caster Capacity(kg) | ||||||
| plate Rigid | M-DP02-7531GSUS304E | 3”/75 | 31 | 108.5 | 2.5mm/170kg | 100 | PU | PP | Steel Single bail 单轴6002 | 1.Derlin+304 Tube/特尔灵 第4位数字改成6 2.440C Double bail 双轴 440C-6001 第4位数字改成B 3.SUS304 Double bail 双轴 304-6001 第4位数字改成S 4.SUS304 Double bail 单轴 304-6002 第4位数字改成C 5.Hi-Temp. Bearing can not changed 高温轴承不可替代 |
| M-DP32-7531GSUS304E | 80 | TPR | ||||||||
| M-DP58-7531GSUS304E | 100 | PP | Steel Double bail 双轴6001 | |||||||
| M-DPFH-7533GSUS304E | 33 | 100 | Fiberglass+PA | Fiberglass+PA | Hi-temp Steel Double bail 高温双轴6001 | |||||
| M-DP02-10031GSUS304E | 4”/100 | 31 | 132 | 110 | PU | PP | Steel Single bail 单轴6002 | |||
| M-DP32-10031GSUS304E | 90 | TPR | ||||||||
| M-DP58-10031GSUS304E | 110 | PP | Steel Double bail 双轴6001 | |||||||
| M-DPFH-10033GSUS304E | 33 | 110 | Fiberglass+PA | Fiberglass+PA | Hi-temp Steel Double bail 高温双轴6001 | |||||
| M-DP02-12531GSUS304E | 5”/125 | 31 | 161 | 120 | PU | PP | Steel Single bail 单轴6002 | |||
| M-DP32-12531GSUS304E | 100 | TPR | ||||||||
| M-DP58-12531GSUS304E | 120 | PP | Steel Double bail 双轴6001 | |||||||
| M-DPFH-12533GSUS304E | 33 | 120 | Fiberglass+PA | Fiberglass+PA | Hi-temp Steel Double bail 高温双轴6001 |
